Chemical Hose :
Application: As Chemical Rubber Hose manufacturer Designed to handle a wide range of chemicals, acids, alkalies and alcoholic, mineral acids, aqueous solution of inorganic materials during production and their transferring operations.
Lining : Uniform seamless tube of EPDM, Hypalon, Thiokol, Chloroprene, Butyl, SBR, NBR, natural/synthetic/blend rubber compound or a blend depending on the liquid for which the hose is intended to be used.
Reinforcement : Plies of rubber coated woven textile or braided synthetic yarns with or without helical galvanized steel wire.
Cover : Smooth, fluted or fabric marked finish with suitable rubber compound, resistant to weather.
Types : Type 1 for conveying dilute chemicals. Type 2 for conveying concentrated chemicals.
Pressures: Type 1 W.P. of 1.00 MPa & B.P. min.3.15 MPa . Type 2 W.P. of 1.00 MPa & B.P. min.4.00 MPa Nom
Pressures: W.P. of 1.0 MPa & min. B. P. 4.0 MPa.
| Nom. Bore in (mm) | Tolerance on Nom. bore (mm) | Min. Thk. of Lining (mm) | Min. Thk. of Cover (mm) |
|---|---|---|---|
| 10.00 | ± 0.75 | 2.0 | 1.3 |
| 12.50 | ± 0.75 | 2.0 | 1.3 |
| 16.00 | ± 0.75 | 2.0 | 1.3 |
| 20.00 | ± 0.75 | 2.0 | 1.3 |
| 25.00 | ± 1.25 | 2.0 | 1.3 |
| 31.50 | ± 1.25 | 2.0 | 1.3 |
| 38.00 | ± 1.50 | 2.0 | 1.3 |
| 45.00 | ± 1.50 | 2.0 | 1.3 |
| 50.00 | ± 2.00 | 2.0 | 1.3 |
W.P. :Working Pressure, P.P. : Proof Pressure, B.P. : Burst Pressure, 1MPa : 10.2Kgf/Cm2 1Kgf/Cm2 :100KN/m2 Length : Mandrel made hose upto 20 mtr., Moulded braided hose in continuos long length.
